Haydon HAY-FIRE-ISO Single Channel Short Circuit Isolator Module for Fire Alarm Systems
The Haydon HAY-FIRE-ISO is a professional short circuit isolator module developed to protect fire detection and alarm systems against wiring faults that could otherwise disable an entire detection circuit. By automatically isolating sections affected by a short circuit, the module ensures that the remainder of the system continues to operate, helping maintain fire protection throughout the building.
Designed for use within conventional fire alarm installations, the HAY-FIRE-ISO continuously monitors the circuit for abnormal conditions. If a short circuit is detected, the module immediately disconnects the faulty section while allowing devices on the unaffected part of the circuit to remain operational. Once the fault has been cleared, the isolator automatically reconnects the circuit without requiring manual intervention, helping to minimise system downtime.
KEY FEATURES
- Single-channel short circuit isolator module
- Automatically isolates wiring short circuits
- Protects conventional fire alarm circuits
- Maintains operation of unaffected devices
- Automatic reconnection after fault clearance
- Improves system reliability and continuity
- Compact design for discreet installation
- Suitable for new installations and retrofits
- Simple wiring for straightforward installation
- Designed for professional fire detection systems
- Ideal for commercial, industrial and public buildings
- Robust and reliable operation
