Nice MYGO2 2 Channel Transmitter
Unless selecting a vari-focal camera (with an adjustable lens) It is important to select the correct camera lens option for where the camera is to be positioned. A smaller lens will give you a wider angle but will be "zoomed out more", while a bigger lens will narrow the angle down and "zoom in more". See below to give you some idea on angles of Megapixel HD Cameras:
| Lens in mm | Approx Viewing Angle (degrees) | Ideal Distance (metres) | Typical usage/notes |
|---|---|---|---|
| 2.8 | 106 | <6 | For seeing as much of the immediate area as possible such as above a doorway/low down/garage soffits (edges can appear slightly warped/distorted) - clearly "zoomed out" |
| 3.6/4 | 83-90 | <12 | A great general purpose option giving great coverage still in the corner of a room or higher up on second floor soffits with less distortion - more of a natural "zoom" |
| 6 | 56 | 6-20 | Narrows down the angle and zooms in to look past the immediate area a little to gain more detail - down a driveway for example from higher up |
| 12 | 24 | 20+ | Zooms in significantly more to look at a gate, entrance or adjascent building |
| 16 | 19 | 24+ | As above but more so |
The amount of hard drive space you require is dictated by how many cameras, as well as their resolution and frame rate settings. Finally you can often make your storage space last a lot longer by enabling motion detected recording rather than continuous, especially if there are long periods of no activity.
|
Resolution (Megapixels) |
Days of storage provided by 1TB per camera (continuous - full 25 frames per second) |
Days of storage provided by 1TB per 4 cameras (continuous - full 25 frames per second) |
Days of storage provided by 1TB per 4 cameras (50% motion- 15 frames per second) |
|---|---|---|---|
| 1 | 44 | 11 | 36 |
| 2 | 22 | 5 | 18 |
| 3 | 17 | 4 | 14 |
| 4 | 11 | 3 | 9 |
| 5 | 9 | 2 | 8 |
| 6 | 8 | 2 | 6 |
| 8 (4K) | 5 | 1 | 4 |
| 12 | 4 | 0.5 | 3 |
As a rule of thumb we recommend a minimum of 2 Terabytes per 4 x 2-4MP HD cameras, as this should give you 2 weeks to a month with a few adjustments on motion detected recording. You may only require the full 25 frames per second on certain cameras if things are fast moving.
(All of our hard drives come fitted and are CCTV specific from one of the major brands)
- FREE UK Mainland Delivery for orders over £240
- Premium Services Available and Worldwide
- View all details here
12/24/36 months warrantiesGuarantee for all purchased goods in our online store is 1 year, most are 2.
1 Hour Delivery window notificationYou receive SMS messages about each stage of your order.
Return and exchange with easeYou can return the items purchased within 14 days. The goods must be in normal condition and have all the factory packages.
Price match promiseWe will match or beat any other Authorized Reseller.
- Debit/Credit Card
- Visa, MasterCard, AMEX
- Paypal (Inc finance)
- Bank transfer (BACS)
The MYGO transmitter has a secret code, the so-called “ENABLING CODE”. By transferring the programmed code from a memorised transmitter to a new transmitter, the new transmitter is recognised (and memorised) automatically by the receiver.
MYGO transmitters operate by default with the Unidirectional “O-Code” radio encoding system. To satisfy backward-compatibility requirements, MYGO transmitters can operate with the ET Blue, Piccinin and Linear encoding systems.
Low battery warning via red flashes of the info LED during transmission. Available in bi-directional version as well: 2, 4 and 8 buttons depending on customer needs.
By programming in Mode 1 according to the manual, this allows you to memorise all the transmitter keys, at once, in the receiver. The 2 keys are automatically associated to each control managed by the Control Unit according to a factory-set sequence
Specification
TECHNICAL SPECIFICATIONS
Product type Unidirectional transmitter
Power supply 3 Vdc lithium battery type CR2430
Battery life approx. 3 years, with 10 command transmissions per day
Frequency 433.92 MHz
Radiated power (ERP) < 10 mW
Radio encoding O-Code ET Blue, Peccinin and Linear
Operating temperature -5°C … +55 °C
Protection rating IP 30 (suitable for use at home indoors or in outdoor areas under cover)
Dimensions 72 x 34 x 110h mm
Weight 20 g
