Ruijie RG-CS86-12XMG4VS-UP 16-Port Multi-Gigabit Layer 3 Cloud Managed PoE++ Switch with 4 × 25GE SFP28 Uplinks
Unless selecting a vari-focal camera (with an adjustable lens) It is important to select the correct camera lens option for where the camera is to be positioned. A smaller lens will give you a wider angle but will be "zoomed out more", while a bigger lens will narrow the angle down and "zoom in more". See below to give you some idea on angles of Megapixel HD Cameras:
| Lens in mm | Approx Viewing Angle (degrees) | Ideal Distance (metres) | Typical usage/notes |
|---|---|---|---|
| 2.8 | 106 | <6 | For seeing as much of the immediate area as possible such as above a doorway/low down/garage soffits (edges can appear slightly warped/distorted) - clearly "zoomed out" |
| 3.6/4 | 83-90 | <12 | A great general purpose option giving great coverage still in the corner of a room or higher up on second floor soffits with less distortion - more of a natural "zoom" |
| 6 | 56 | 6-20 | Narrows down the angle and zooms in to look past the immediate area a little to gain more detail - down a driveway for example from higher up |
| 12 | 24 | 20+ | Zooms in significantly more to look at a gate, entrance or adjascent building |
| 16 | 19 | 24+ | As above but more so |
The amount of hard drive space you require is dictated by how many cameras, as well as their resolution and frame rate settings. Finally you can often make your storage space last a lot longer by enabling motion detected recording rather than continuous, especially if there are long periods of no activity.
|
Resolution (Megapixels) |
Days of storage provided by 1TB per camera (continuous - full 25 frames per second) |
Days of storage provided by 1TB per 4 cameras (continuous - full 25 frames per second) |
Days of storage provided by 1TB per 4 cameras (50% motion- 15 frames per second) |
|---|---|---|---|
| 1 | 44 | 11 | 36 |
| 2 | 22 | 5 | 18 |
| 3 | 17 | 4 | 14 |
| 4 | 11 | 3 | 9 |
| 5 | 9 | 2 | 8 |
| 6 | 8 | 2 | 6 |
| 8 (4K) | 5 | 1 | 4 |
| 12 | 4 | 0.5 | 3 |
As a rule of thumb we recommend a minimum of 2 Terabytes per 4 x 2-4MP HD cameras, as this should give you 2 weeks to a month with a few adjustments on motion detected recording. You may only require the full 25 frames per second on certain cameras if things are fast moving.
(All of our hard drives come fitted and are CCTV specific from one of the major brands)
- FREE UK Mainland Delivery for orders over £240
- Premium Services Available and Worldwide
- View all details here
12/24/36 months warrantiesGuarantee for all purchased goods in our online store is 1 year, most are 2.
1 Hour Delivery window notificationYou receive SMS messages about each stage of your order.
Return and exchange with easeYou can return the items purchased within 14 days. The goods must be in normal condition and have all the factory packages.
Price match promiseWe will match or beat any other Authorized Reseller.
- Debit/Credit Card
- Visa, MasterCard, AMEX
- Paypal (Inc finance)
- Bank transfer (BACS)
Ruijie RG-CS86-12XMG4VS-UP 16-Port Multi-Gigabit Layer 3 Cloud Managed PoE++ Switch with 4 × 25GE SFP28 Uplinks
The Ruijie RG-CS86-12XMG4VS-UP is an enterprise-grade Layer 3 managed switch engineered to meet the increasing bandwidth requirements of modern campus, enterprise and data-intensive networks. Combining Multi-Gigabit access, high-power PoE++, advanced Layer 3 routing and intelligent cloud management, it provides exceptional performance for next-generation wireless networks, high-resolution surveillance systems and demanding business applications. The switch features 12 auto-negotiating 100M/1G/2.5G/5G/10GBASE-T RJ45 ports, all supporting IEEE 802.3af/at/bt PoE++, alongside 4 × 10GE/25GE SFP28 uplink ports for ultra-fast fibre connectivity. Each PoE++ port can deliver up to 90W, while the integrated power supply provides a maximum 460W PoE output, making the switch ideal for powering Wi-Fi 6E and Wi-Fi 7 access points, PTZ cameras, video conferencing equipment and other high-power network devices. Designed for continuous enterprise operation, the RG-CS86-12XMG4VS-UP incorporates VSU virtualisation, hardware boot redundancy, optical port fault isolation, CPP (CPU Protection Policy), NFPP (Network Foundation Protection Policy) and intelligent hardware monitoring to maximise reliability and network resilience. Advanced Layer 2 and Layer 3 capabilities include VLANs, static routing, QoS, multicast management, ACLs, link aggregation and comprehensive security policies for complex network deployments.
KEY FEATURES
- 16-port Layer 3 cloud managed Multi-Gigabit switch
- 12 × Multi-Gigabit RJ45 ports supporting 100M/1G/2.5G/5G/10G
- 4 × 10GE/25GE SFP28 fibre uplink ports
- IEEE 802.3af/at/bt PoE, PoE+ and PoE++ support
- Up to 90W PoE output per port
- Maximum 460W PoE power budget
- Designed for Wi-Fi 6E and Wi-Fi 7 deployments
- Layer 2 and Layer 3 switching and routing
- VSU virtualisation for simplified network architecture
- Hardware boot redundancy for enhanced reliability
- Optical port fault isolation
- CPU Protection Policy (CPP) and NFPP security
- VLAN, QoS, ACL, Link Aggregation and Static Routing
- Ruijie Cloud remote management with zero-touch provisioning
- Web GUI, CLI, SNMP and Telnet management
