NVR 8 Channel 2 SATA 12MP Max UV-NVR302-08E2-P8-IQ (End of life)
Unless selecting a vari-focal camera (with an adjustable lens) It is important to select the correct camera lens option for where the camera is to be positioned. A smaller lens will give you a wider angle but will be "zoomed out more", while a bigger lens will narrow the angle down and "zoom in more". See below to give you some idea on angles of Megapixel HD Cameras:
| Lens in mm | Approx Viewing Angle (degrees) | Ideal Distance (metres) | Typical usage/notes |
|---|---|---|---|
| 2.8 | 106 | <6 | For seeing as much of the immediate area as possible such as above a doorway/low down/garage soffits (edges can appear slightly warped/distorted) - clearly "zoomed out" |
| 3.6/4 | 83-90 | <12 | A great general purpose option giving great coverage still in the corner of a room or higher up on second floor soffits with less distortion - more of a natural "zoom" |
| 6 | 56 | 6-20 | Narrows down the angle and zooms in to look past the immediate area a little to gain more detail - down a driveway for example from higher up |
| 12 | 24 | 20+ | Zooms in significantly more to look at a gate, entrance or adjascent building |
| 16 | 19 | 24+ | As above but more so |
The amount of hard drive space you require is dictated by how many cameras, as well as their resolution and frame rate settings. Finally you can often make your storage space last a lot longer by enabling motion detected recording rather than continuous, especially if there are long periods of no activity.
|
Resolution (Megapixels) |
Days of storage provided by 1TB per camera (continuous - full 25 frames per second) |
Days of storage provided by 1TB per 4 cameras (continuous - full 25 frames per second) |
Days of storage provided by 1TB per 4 cameras (50% motion- 15 frames per second) |
|---|---|---|---|
| 1 | 44 | 11 | 36 |
| 2 | 22 | 5 | 18 |
| 3 | 17 | 4 | 14 |
| 4 | 11 | 3 | 9 |
| 5 | 9 | 2 | 8 |
| 6 | 8 | 2 | 6 |
| 8 (4K) | 5 | 1 | 4 |
| 12 | 4 | 0.5 | 3 |
As a rule of thumb we recommend a minimum of 2 Terabytes per 4 x 2-4MP HD cameras, as this should give you 2 weeks to a month with a few adjustments on motion detected recording. You may only require the full 25 frames per second on certain cameras if things are fast moving.
(All of our hard drives come fitted and are CCTV specific from one of the major brands)
- FREE UK Mainland Delivery for orders over £240
- Premium Services Available and Worldwide
- View all details here
12/24/36 months warrantiesGuarantee for all purchased goods in our online store is 1 year, most are 2.
1 Hour Delivery window notificationYou receive SMS messages about each stage of your order.
Return and exchange with easeYou can return the items purchased within 14 days. The goods must be in normal condition and have all the factory packages.
Price match promiseWe will match or beat any other Authorized Reseller.
- Debit/Credit Card
- Visa, MasterCard, AMEX
- Paypal (Inc finance)
- Bank transfer (BACS)
Uniview NVR 8 Channel 2 SATA 12MP Max UV-NVR302-08E2-P8-IQ 5MP Tri-Guard Fixed Dual-Light Turret Network Camera
The UV-NVR302-08E2-P8-IQ is a powerful 8-channel AI Network Video Recorder designed for high-performance IP surveillance applications. Featuring 8 built-in PoE ports, this NVR simplifies installation by delivering both power and data through a single Ethernet cable for connected cameras.
Supporting Ultra H.265, H.265, and H.264 compression technologies, the recorder significantly reduces bandwidth and storage consumption while maintaining exceptional image quality. With support for up to 12MP recording resolution and HDMI 4K video output, users can experience crystal-clear live viewing and playback performance.
This intelligent NVR includes advanced AI functions such as facial recognition, people counting, intrusion detection, line crossing detection, crowd density monitoring, vehicle search, and smart intrusion prevention. It is ideal for homes, offices, warehouses, retail stores, commercial buildings, and enterprise security deployments.
The device supports 2 SATA hard drives up to 10TB each for large-scale video storage and includes ANR technology for reliable recording during network interruptions. Its ONVIF compatibility ensures seamless integration with a wide range of IP cameras and surveillance systems.
Key Features
- 8-channel IP network video recorder
- Built-in 8 PoE ports for easy Plug & Play installation
- Ideal for commercial and enterprise surveillance systems
- Intelligent motion detection and VCA search features
- USB 2.0 and USB 3.0 backup support
- Supports cloud upgrade and remote monitoring
- ONVIF compatible with third-party IP cameras
- ANR technology for reliable recording during network failure
- 2 SATA interfaces supporting up to 10TB each
- Vehicle search and LPR camera compatibility
- Intrusion detection and line crossing alerts
- Supports people counting and crowd density monitoring
- Smart AI analytics with facial recognition and SIP
- HDMI 4K and VGA simultaneous video output
- Up to 12MP recording resolution support
- Supports Ultra H.265 / H.265 / H.264 compression
