8MP TriGuard 3.0 Turret White UV-IPC3634SE-ADF28KMC-WP-I1-B
Unless selecting a vari-focal camera (with an adjustable lens) It is important to select the correct camera lens option for where the camera is to be positioned. A smaller lens will give you a wider angle but will be "zoomed out more", while a bigger lens will narrow the angle down and "zoom in more". See below to give you some idea on angles of Megapixel HD Cameras:
| Lens in mm | Approx Viewing Angle (degrees) | Ideal Distance (metres) | Typical usage/notes |
|---|---|---|---|
| 2.8 | 106 | <6 | For seeing as much of the immediate area as possible such as above a doorway/low down/garage soffits (edges can appear slightly warped/distorted) - clearly "zoomed out" |
| 3.6/4 | 83-90 | <12 | A great general purpose option giving great coverage still in the corner of a room or higher up on second floor soffits with less distortion - more of a natural "zoom" |
| 6 | 56 | 6-20 | Narrows down the angle and zooms in to look past the immediate area a little to gain more detail - down a driveway for example from higher up |
| 12 | 24 | 20+ | Zooms in significantly more to look at a gate, entrance or adjascent building |
| 16 | 19 | 24+ | As above but more so |
The amount of hard drive space you require is dictated by how many cameras, as well as their resolution and frame rate settings. Finally you can often make your storage space last a lot longer by enabling motion detected recording rather than continuous, especially if there are long periods of no activity.
|
Resolution (Megapixels) |
Days of storage provided by 1TB per camera (continuous - full 25 frames per second) |
Days of storage provided by 1TB per 4 cameras (continuous - full 25 frames per second) |
Days of storage provided by 1TB per 4 cameras (50% motion- 15 frames per second) |
|---|---|---|---|
| 1 | 44 | 11 | 36 |
| 2 | 22 | 5 | 18 |
| 3 | 17 | 4 | 14 |
| 4 | 11 | 3 | 9 |
| 5 | 9 | 2 | 8 |
| 6 | 8 | 2 | 6 |
| 8 (4K) | 5 | 1 | 4 |
| 12 | 4 | 0.5 | 3 |
As a rule of thumb we recommend a minimum of 2 Terabytes per 4 x 2-4MP HD cameras, as this should give you 2 weeks to a month with a few adjustments on motion detected recording. You may only require the full 25 frames per second on certain cameras if things are fast moving.
(All of our hard drives come fitted and are CCTV specific from one of the major brands)
- FREE UK Mainland Delivery for orders over £240
- Premium Services Available and Worldwide
- View all details here
12/24/36 months warrantiesGuarantee for all purchased goods in our online store is 1 year, most are 2.
1 Hour Delivery window notificationYou receive SMS messages about each stage of your order.
Return and exchange with easeYou can return the items purchased within 14 days. The goods must be in normal condition and have all the factory packages.
Price match promiseWe will match or beat any other Authorized Reseller.
- Debit/Credit Card
- Visa, MasterCard, AMEX
- Paypal (Inc finance)
- Bank transfer (BACS)
The Uniview UV-IPC3634SE-ADF28KMC-WP-I1-B is a professional 4MP dual-light eyeball network camera designed for intelligent outdoor surveillance and advanced AI-powered security monitoring. Featuring a high-performance 1/1.8" CMOS sensor with an F1.0 large-aperture lens, the camera delivers ultra-clear full-color video even in extremely low-light environments using ColorHunter and Wise-ISP technologies. It supports intelligent perimeter protection with accurate human, vehicle, and non-motor vehicle detection while minimizing false alarms caused by lights, animals, or environmental movement.
Equipped with Smart IR and warm light illumination up to 30 meters, the camera ensures reliable day and night visibility. The built-in dual microphones and speaker support two-way audio communication and active deterrence functions for enhanced real-time security response. With 130dB True WDR, IP67 weatherproof protection, IK10 vandal resistance, NEMA 4X certification, MicroSD storage up to 512GB, and PoE support, this camera is ideal for homes, offices, warehouses, parking areas, retail stores, and industrial security applications.
- 4MP Ultra HD resolution with crystal-clear imaging
- 1/1.8" CMOS sensor with F1.0 large-aperture lens
- ColorHunter technology for 24/7 full-color monitoring
- Dual-light system with IR and warm light up to 30m
- AI smart detection for humans, vehicles, and intrusion events
- Active deterrence with built-in speaker and warning alerts
- Built-in dual microphones for enhanced audio recording
- 130dB True WDR for balanced imaging in strong light
- Supports H.265 / Ultra 265 video compression
- MicroSD card support up to 512GB
- IP67 weatherproof and IK10 vandal-resistant design
- ONVIF compatible for seamless NVR integration
- PoE support for easy installation and power delivery
- Ideal for residential, commercial, retail, and industrial surveillance systems
